At Illuminated Extractors, we believe scaling your extraction operation shouldn’t just be additional material columns and chillers. Trying to increase throughput by simply adding capacity and ancillary equipment is counterproductive. In fact, it makes your lab less efficient and more vulnerable with every additional piece of ancillary equipment. That’s why we created the E4K Extractor Series—the most modular, upgradable extraction platform designed to evolve with your production demands. And when you’re ready to scale, “T” is for Turbo.
In this blog, we’ll break down the full range of E-4K models, from the base unit to our high-performance Turbo and MAX configurations. What’s unique about our scalable platform, is the numerous ways to scale. If you want to increase capacity, or speed up recovery, we got you covered. Whether you’re launching a lean lab or expanding to meet serious commercial demand, there’s an E4K built to grow with you.
Don’t let the word “base” fool you. The standard E-4K is a turnkey hydrocarbon extraction system, engineered to process approximately 12 pounds per hour of cold extraction without relying on separate chillers or heaters.
Thanks to our ProJak™ DX Refrigeration System, the E-4K maintains temps of lower than -50C, preserving terpenes, reducing post-processing, and minimizing your energy footprint. It’s optimized for both live (wet) and cured (dry) material—no need to change equipment for different input types.
This configuration utilizes the IE T-091 Process Compressor and includes our patented GD-1 Rotary Solvent Evaporator, which can evaporate 20 lbs. of solvent per minute. It uniquely boils off your solvent under pressure, not vacuum. This accelerates evaporation and streamlines the workflow without the need for additional ancillary equipment.
• Reduces the biggest bottleneck in extraction: solvent recovery
• Slashes processing time while maintaining product quality
• Eliminates the need for third-party heaters and chillers
The T300 builds on the T200 by adding the IE-291 Process Compressor, a game-changing upgrade that eliminates the final recovery bottleneck for high-throughput labs.
The IE-291 Compressor is designed to manage heavier solvent volumes with ease, ensuring continuous, balanced operation and optimized flow. It’s perfect for labs processing large volumes or running multiple skews back-to-back.
When your demand goes up, so can your columns. The MAX configuration boosts your input capacity by 50% to 100%, either by increasing column diameter (from 4″ to 6″) or by doubling the number of extraction columns./p>
The E4K MAX isn’t about bells and whistles—it’s about maximizing every dollar of labor, energy, and equipment cost. The modularity allows you to match system growth with market demand, rather than overspending upfront.
The brilliance of the E-4K Series lies in its numerous ways to scale up by way of capacity and evaporation rates. You can start with the base model and move up to the T200, T300, or the largest and fastest model in the series, the E-4K T300-MAX configurations, as your operation grows. There’s no need to rip out and replace equipment when you can expand and evolve.
And with Illuminated Extractors’ proven engineering, PSI peer-review certifications, and customer-first support, the E-4K isn’t just another piece of equipment. It’s a long-term investment in your lab’s future..
